Product Details

Features of Hetaifeng scissor lift platform:

The HXPT series self-propelled scissor aerial work platform makes many difficult and dangerous jobs easier, such as: indoor and outdoor cleaning (ceilings, curtain walls, glass windows, eaves, awnings, chimneys, etc.), installation and maintenance of billboards, installation and maintenance of street lights and traffic signs, etc. This aerial lift platform is characterized by its compactness, flexibility, convenience, and speed. You can use an aerial lift platform instead of scaffolding to reach the height you need and solve your problems. At the same time, it can save you costs and valuable time. It is especially suitable for large-scale continuous high-altitude operations in airport terminals, stations, docks, shopping malls, stadiums, community properties, factory workshops, and other places.

Product Features:
1) Safety Certification
Obtained CE certification.
2) Walkable for High-Altitude Operations
It has an automatic walking function, capable of fast and slow movement in different working states. Only one person is needed to operate the machine for continuous lifting, forward, backward, and turning actions during high-altitude operations, significantly improving work efficiency and reducing the number of operators and labor intensity compared to traditional hydraulic platforms.
3) Stepless Speed Regulation
Only one person is needed to operate it; all movements are controlled by the operating handle on the platform, and the motor has stepless speed regulation. This effectively extends the service life of the battery and motor, as the motor only consumes energy when working.
4) Large-Angle Steering System
It uses a hydraulic steering system, giving the machine excellent flexibility.
5) Smart Charging System
Equipped with a fully automatic charger that automatically completes the entire charging process and stops charging automatically when the battery is full.
6) Extension Platform (Optional Item)
The work platform can be extended, expanding the working range and meeting the special needs of some users.
7) Power Outage Self-Locking Function
Automatically locks at the current height during a power outage or sudden power failure
8) Environmentally Friendly
Since this machine uses DC battery power, it is safe and quiet for both indoor and outdoor work.
9) Emergency Device
Equipped with an emergency lowering system


Parameter:

Model (self-propelled hydraulic drive)

    GTJZ-10

Maximum working height

12m

Maximum platform height

10m

safe working load

320kg

Extended platform
safe working load

100kg

Working platform dimensions
(length × width × height)

2.26×1.14×1.1m

Overall dimensions
(guardrails not folded)

2.41×1.16×2.44m

Overall dimensions
(guardrail folded)

2.41×1.16×1.72m

Extended size of table

0.9m

Minimum ground clearance

0.1/0.02m

wheelbase

1.87m

Turning radius
(inner wheel/outer wheel)

0/2.35m

Lifting/drive motor

24V/4.5kw

Lifting speed

3-5m/min

Machine travel speed
(folded state)

3.5km/h

Machine travel speed
(lifting state)

0.8km/h

batteries

4×6V/260ah

charger

24V/30A

Maximum climbing ability

25%

Maximum
allowable working angle

1.5°/3°

tire

Φ381×127mm

Machine weight

2900kg
